TDS Controller 2 Set Point
10 Days Returnable;
Heavy Duty Industrial use 24×7 working
1 Year Warranty and 6-7 years nominal Life in a Normal Atmosphere.
TDS Controller 2 Set Point
TDS Controller with Two Set Point and 2 Relay Output
Set the High and Low values of TDS using SET, UP, and down Buttons, and Save the value by pressing the ENT button.
The 2 separate relays will trigger high and low values and change their state NO/NC (5A) Contact, both relays have potential-free contact that may use to start 2 pumps for high and low levels seperatly.
What is TDS?
The PPM (Particle per Million) TDS value (Total Dissolved Solids) gives the sum of total dissolved solids in water. These solids may be salts, minerals, and metals. Mostly Sodium and magnesium salt fond dissolved. TDS measred in PPM.
Conductivity Means: The conductivity of the water or any solid/liquid measured indicates ions are in the water, the better it conducts electricity. TDS meters typically quantify this conductivity in micro siemens UCM or MCM. The latter stands for parts per million, i.e. the number of solid particles per one million water mixture particles. A value of 40 ppm means that from one million particles there are 40 dissolved ions and the rest (= 999 960) are water molecules.
What does it mean about the water quality?
DM water with a ppm value of zero is automatically free from any pesticides and drug residues, is far from it. All the TDS meter measures are merely the number of ions in the water. Most of the pesticides, hormone-disturbing substances, and drug residues are usually no ions!
In short: water with a low ppm value is virtually free from salts and minerals, but can hide a large cocktail of non-ionic chemicals in itself. The result of a TDS meter is therefore not very meaningful with regard to the actual water quality. while Other analytical methods or a water analysis by a reputable laboratory may be better suited to find out about the actual water quality.
Observation as analyst
if you want to check the functionality of an osmosis system, the mere TDS values are not suitable as an indicator of the water quality. Hence extensive and detailed water analyzes are often very expensive and only reflect a snapshot, they are only advisable if the drinking water is to be tested for individual substances. It often makes more sense to invest in a high-quality water filter right away. This way you have more security with your daily drinking water consumption in the long term. However, it is essential to pay attention to appropriate assessments and long-term studies! Because the label “filters pesticides” can also mean, with an inferior filter, that only 5% of the pesticides are removed, or the retention rate drops rapidly after a short time.
- Range : 0000 to 9999 PPM
- Resolution : 1 PPM
- Tolerence : +/- 1 PPM
- Output: 2 Potential free relay Output with Display
- Calibration: Front back Panel knob;
- Input: Conductivity cell Probe any Brand
- Display: Seven-Segment Bright LED Display
- Operating Voltage: 220 Vac
- Size : 96 * 96 * 110
- Body: PP/ABS
by front-back panel knob
